DELL PowerEdge R230

Form factor

1U rack server

Processor

1 processor from the following product families:

• Intel® Xeon® processor E3-1200 v5 product  family
• Intel Pentium®
• Intel CoreTM i3

Chipset

Intel C236

Operating system

Microsoft® Windows Server® 2012 Microsoft Windows Server 2012 R2, x64 Red Hat® Enterprise Linux®

VMware® Vsphere® 2015

Memory

Architecture: Up to 2133MT/s DDR4 DIMMs Memory type: UDIMMs

Memory module sockets: 4 Maximum RAM: Up to 64GB

Hypervisor support

Microsoft Windows Server with Hyper-V® Citrix®  XenServer®

VMware®  vSphere® ESXi®

Storage

• 2.5” SSD SATA
• 2.5” SATA 7.2K
• 2.5” SAS 15K HDs
• 2.5” nearline SAS 7.2K
• 2.5” SAS 10K HDs
• 3.5” Enterprise SATA 7.2K HDDs
• 3.5” nearline SAS 7.2K HDDs
• 3.5” 7.2K SATA entry drives

Drive bays

2 x 3.5” cabled HDD

4 x 3.5” cabled HDD

4 x 3.5” hot-swap or 2.5” hot-swap in hybrid drive carrier

Slots

2 x PCIe 3.0 slots: x16 slot, full height (1x8 3.0)+ x8 slot,low profile (1x4 3.0)

RAID controllers

PERC S130, PERC H330, PERC H730, PERC H830

Network controller

Broadcom®  5720

Communications

Broadcom quad-port 1Gb Base-T adapter Broadcom dual-port 1Gb Base-T adapter

Power

250W cabled PSU

Chassis

• 2 x 3.5” cabled HDD 19.5” 1U chassis
• 4 x 3.5” cabled HDD 19.5” 1U chassis
• 4 x 3.5” hot-swap or 2.5” hot-swap in hybrid drive carrier

Management

Systems management:

• • IPMI 2.0 compliant
• • Dell OpenManage Essentials
• • Dell  OpenManage Mobile
• • Dell OpenManage Power Center

Dell  OpenManage Integrations:

• • Dell OpenManage Integration Suite for Microsoft System Center
• • Dell OpenManage Integration for VMware vCenter®

Dell  OpenManage Connections:

• • HP Operations Manager, IBM Tivoli® Netcool® and CA Network and Systems Management
• • Dell OpenManage Plug-in for Oracle® Database Manager

Remote management:

iDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade),

8GB vFlash media (upgrade),16GB vFlash media (upgrade)

Device Access

5 total USB:

Rear: 2 x USB 3.0 ports

Front: 2 x USB 2.0 ports

Internal: 1 x USB 3.0 port

Rack Support

ReadyRails™ II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional

tool-less cable management  arm.

Dimensions

Depth without Bezel : 495.0 mm (19.5 in) Depth with Bezel : 676.92mm (20.8 In) Height : 42.8mm (1.68 in)

Width without rack latches : 434.0mm (17.08 in) Width with rack latches : 482.4mm (18.99 in)
