DELL PowerEdge R740xd

Processor

Up to two Intel® Xeon® SP, up to 28 cores per processor

Memory

24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2666MT/s, 3TB max Up to 12 NVDIMM, 192 GB Max

Supports registered ECC DDR4 DIMMs only

Storage controllers

Internal controllers: PERC H730p, H740p, HBA330, Software RAID (SWRAID) S140 External PERC (RAID): H840

External HBAs (non-RAID): 12 Gbps SAS HBA

Boot Optimized Storage Subsystem:  HWRAID 2 x M.2 SSDs 120GB or 240 GB

Drive bays

Front bays: Up to 24 x 2.5 SAS/SATA (HDD/SSD), NVMe SSD max 153TB or up to 12 x 3.5” SAS/SATA HDD max 120TB Mid bay: Up to 4 x 2.5”, max 25TB SAS/SATA (HDD/SSD), NVMe SSD max 25TB or up to 4 x 3.5”, max 40TB

Rear bays: Up to 4 x 2.5”, max 25TB SAS/SATA (HDD/SSD), NVMe SSD or up to 2 x 3.5” max 20TB SAS/SATA HDD

Power supplies

Titanium 750W, Platinum 495W, 750W, 1100W,

1600W, and 2000W

Dimensions

Form factor: Rack (2U)

Embedded management

IPMI 2.0 compliant

iDRAC9 with Lifecycle Controller (Express, Enterprise)

Quick Sync 2 wireless module optional

Bezel

Optional LCD Bezel or Security bezel

OpenManage™ Software

OpenManage Enterprise OpenManage Essentials

Integrations and

connections

Integrations: Microsoft® System Center,

VMware® vCenter™, BMC Software

Connections: Nagios & Nagios XI, Oracle Enterprise Manager,

Security

TPM 1.2/2.0 optional Cryptographically signed firmware Secure Boot

I/O & Ports

Network daughter card options

4 x 1GE or 2 x 10GE + 2 x 1GE or 4 x 10GE or 2 x 25GE

Front ports: VGA, 2 x USB 2.0, dedicated IDRAC Direct Micro-USB Rear ports: VGA, Serial, 2 x USB 3.0, dedicated iDRAC network port Video card: VGA

Riser options with p to 8 PCIe Gen 3 slots, maximum of 4 x 16 slots

GPU options

GPU options available only on 24 x 2.5” drive chassis Nvidia Tesla P100, K80, K40, Grid M60, M10, P4, Quadro P4000.  AMD S7150, S7150X2

Supported operating systems

Canoniеакнгкагн cal® Ubuntu® LTS Citrix® XenServer®

Microsoft Windows Server® with Hyper-V

Red Hat® Enterprise Linux SUSE® Linux Enterprise Server VMware® ESXi
