Cisco DWDM-SFP10G-53.33=

Parameter

Symbol

Minimum

Typical

Maximum

Units

Notes and Conditions

Transmitter

Spectral width

0.2

nm

Full width, -20 dB from maximum, with resolution bandwidth (RBW) = 0.01 nm

Transmitter center wavelength

x - 100

x

x + 100

Pm

Refer to Table 2 for center wavelengths

Side-mode suppression ratio

SMSR

30

dB

Transmitter extinction ratio

9

dB

Transmitter optical output power

Pout

-1.0

3.0

dBm

Average power coupled into single-mode fiber

Receiver

Receiver optical input wavelength

1530

1565

nm

Receiver damage threshold

 4.0

dBm

Receiver overload

-7

dBm

Receiver Power Performance

Units

Range

Notes and Conditions

Performance at 10G LAN and 10G WAN Rates (NO-FEC Applications)

Input power range

dBm

-7 to -23

At BER=1E-12, back-to-back, unamplified link

Input power range (dispersion-limited)

dBm

-7 to -20

At BER=1E-12, -500 to +1600 ps/nm chromatic dispersion*, unamplified link

Input power range (dispersion- and noise-limited)

dBm

-7 to -17

At BER=1E-12, -500 to +1600 ps/nm chromatic dispersion*, amplified link with min 27dB OSNR (0.1nm RBW)

Performance at OTU2/OTU2e rates (FEC applications)

Input power range

dBm

-7 to -27

At BER=1E-3 (pre-EFEC), back-to-back, unamplified link

Input power range (dispersion-limited)

dBm

-7 to -24

At BER=1E-3 (pre-EFEC), -500 to +1300 ps/nm chromatic dispersion, unamplified link

Input power range (dispersion- and noise-limited)

dBm

-7 to -17

At BER=1E-3 (pre-EFEC), -500 to +1100 ps/nm chromatic dispersion, amplified link with min 16dB OSNR (0.1nm RBW)

Input power range (dispersion- and noise-limited)

dBm

-7 to -17

At BER=1E-5 (pre-GFEC), -500 to +1100 ps/nm chromatic dispersion, amplified link with min 19dB OSNR (0.1nm RBW)

Parameter

Symbol

Minimum

Typical

Maximum

Units

Notes and Conditions

Transmitter

Spectral width

0.2

nm

Full width, -20 dB from maximum, with resolution bandwidth (RBW) = 0.01 nm

Transmitter center wavelength

x - 25

x

x + 25

pm

Refer to Table 3 for center wavelengths

Side-mode suppression ratio

SMSR

30

dB

Transmitter extinction ratio

9

dB

Transmitter optical output power

Pout

-1

3.0

dBm

Average power coupled into single-mode fiber

Receiver

Receiver optical input wavelength

1525

1570

nm

Receiver damage threshold

4.0

dBm

Receiver overload

-7.0

dBm

Receiver Power Performance

Units

Range

Notes and Conditions

Performance at 10G LAN and 10G WAN Rates (NO-FEC Applications)

Input power range

dBm

-7 to -23

At BER=1E-12, back-to-back, unamplified link

Input power range (dispersion-limited)

dBm

-7 to -20

At BER=1E-12, -500 to 1600 ps/nm chromatic dispersion, unamplified link

Input power range (dispersion- and noise-limited)

dBm

-7 to -18

At BER=1E-12, -500 to 1600 ps/nm chromatic dispersion, amplified link with min 26dB OSNR (0.1nm RBW)

Performance at OTU2/OTU2e Rates (FEC Applications)

Input power range

dBm

-7 to -27

At BER=1E-3 (pre-EFEC), back-to-back, unamplified link

Input power range (dispersion-limited)

dBm

-7 to -24

At BER=1E-3 (pre-EFEC), -500 to 1300 ps/nm chromatic dispersion, unamplified link

Input power range (dispersion- and noise-limited)

dBm

-7 to -18

At BER=1E-3 (pre-EFEC), -500 to 1100 ps/nm chromatic dispersion, amplified link with min 14.5dB OSNR (0.1nm RBW)

Input power range (dispersion- and noise-limited)

dBm

-7 to -18

At BER=1E-5 (pre-GFEC), -500 to 1100 ps/nm chromatic dispersion, amplified link with min 17dB OSNR (0.1nm RBW)
