Cisco Nexus N9K-C9336PQ

Product Name

Nexus 9336 Aci Spine Switch with 36P 40G

Manufacturer Part Number

N9K-C9336PQ

Product Line

Nexus

Product Series

9300

Product Model

9336PQ

Product Type

Ethernet Switch

Interfaces/Ports

Uplink Port

No

Modular

No

Stack Port

No

Port / Expansion Slot Details

36 x 40 Gigabit Ethernet Expansion Slot

I/O Expansions

Number of Total Expansion Slots

36

Expansion Slot Type

QSFP

Media & Performance

Ethernet Technology

40 Gigabit Ethernet

Network Technology

40GBase-X

Network & Communication

Layer Supported

2

Power Description

Power Source

Power Supply

Management & Protocols

Manageable

No

Physical Characteristics

Compatible Rack Unit

2U

Form Factor

Rack-mountable

Height

3.5"

Width

17.4"

Depth

22.3"

Warranty

Limited Warranty

1 Year

Miscellaneous

Environmentally Friendly

Yes

Environmental Certification

RoHS-6

80 Plus Platinum

Other Information

Product Family

Nexus 9300

PoE (RJ-45) Port

No

Token Ring Port

No

LRE Port

No

USB

No

Management Port

No

Bypass

No

Certifications & Standards

Safety:

• UL 60950-1 Second Edition
• CAN/CSA-C22.2 No. 60950-1 Second Edition
• EN 60950-1 Second Edition
• IEC 60950-1 Second Edition
• AS/NZS 60950-1
• GB4943
• CE

Emissions:

• 47CFR Part 15 (CFR 47) Class A
• AS/NZS CISPR22 Class A
• CISPR22 Class A
• EN55022 Class A
• ICES003 Class A
• VCCI Class A
• EN61000-3-2
• EN61000-3-3
• KN22 Class A
• CNS13438 Class A

Immunity:

• EN55024
• CISPR24
• EN300386
• KN 61000-4

Input Voltage

230 V AC
